Nichrome& Kanthal

The two major types of resistance wire are Kanthal and Nichrome wire.
Kanthal is a ferritic iron-chromium-aluminum alloy that can be in high temperature applications. It is often used in large, industrial applications and chosen for its high resistivity and excellent oxidation resistance.
Nichrome is made from nickel-chromium alloys is generally only used in temperatures below 1250°C.
Nichrome has a slightly lower maximum operating temperature than Kanthal and operates best applications such as hair dryers, toasters, and kilns.

Nichrome 60 Properties

· Melting Temperature: 1350°C (2462°F) · Maximum Operating Temperature: 1150°C (2100°F) · Density: 0.2979 lbs/cubic in. · Specific heat capacity @ 68°F: 0.11 Btu/lb°F · Thermal Expansion: 14 x 10 to the -6 per °C

Kanthal A1 Properties

· Melting Temperature: 1500°C (2732°F) · Maximum Operating Temperature: 1400°C (2550°F) · Density: 0.256 lbs/cubic in. · Specific heat capacity @ 68°F: 0.11 Btu/lb°F

Kanthal D Properties

· Melting Temperature: 1500°C (2732°F) · Maximum Operating Temperature: 1300°C (2370°F) · Density: 0.262 lbs/cubic in. · Specific heat capacity @ 68°F: 0.11 Btu/lb°F

International Grade:

ASME SB-265

Round Bar/Wire:

ASME SB-348 ASTM F-67 AMS 4921 ,AMS 4928,AMS 4957, AMS 4958 , AMS 4965, AMS 4967 ,AMS 4971, AMS 4978, AMS 4979

Pipe:

ASME SB-337, ASME SB-338

Tube:

ASME SB-337, ASME SB-338 AMS 4942 AMS 5582, AMS 5583

Fittings:

ASME SB-363

Forgings:

SME SB-381 MIL-T-9046, MIL-T-9047
